Yale

Reach Assembly & Carriage
Both the carriage and the reach assembly receive a lot of stress during a normal work shift. In order to make certain that the truck keeps productivity levels high, high durability of these things are definitely needed. Yale reach devices are engineered utilizing heavy-duty components for durability and long life. The reach assembly is cushioned at the end of the stroke for great durability and better operator ergonomics. In addition, excellent visibility is provided with the optimal hose routing and the open carriage design.

In order to resist side to side forces, the Reach Assembly Rear Carrier provides durability and rigidity because it is mounted on angle load rollers. Additionally, the stronger inner frame assembly helps to withstand vibration and shocks while handling load. The thick inner frame's side weldments have also been designed for durability.

The Reach Arm Mechanism is made up of tapered roller bearings at reach mechanism pivot points. The pivot points help to reduce the motion side to side and the twisting of the reach assembly throughout rough tasks. In order to decrease carriage twisting, dual reach cylinders are mounted. There are key pivot points which have grease fittings in order to ensure longer service life by providing lubrication.

There are various wires and houses routed through a flexible track in order to decrease potential damage and binding. One more important component is the carriage. There is Reduced Carriage Travel Speed offered with Carriage Extended option so as to prevent high speed travel with the reach assembly extended. This helps to lessen stress on the reach mechanism itself.

Mast
The mast's rigidity and durability are vital to both the operator's confidence and the truck's overall uptime. This is moreso when the reach truck is being operated at tall lift heights. The mast must be rigid enough to resist any twisting caused by the truck's motion or any off-center loading issues. The mast should be sure it could rise and lower in a smooth manner with the least power consumption.
